Description
Product Description
Specification
|
DVR
|
||
|
Video Compression
|
H.265+/H.265/H.264+/H.264
|
|
|
Video Input
|
16CH Analog HD/Analog+2CH IP
|
|
|
Video Output
|
HDMI and VGA Up to 1080P
|
|
|
Audio Input/Output
|
1/1 RCA
|
|
|
Analog HD Recording Resolution
|
1080P Lite(960×1080)/720p(1280×720)：15fps
|
|
|
Analog HD Playback Resolution
|
1080P Lite (960×1080)/720p(1280×720)：15fps
|
|
|
IPC Recording Resolution
|
2CH, Up to 5MP
|
|
|
IPC Playback Resolution
|
2CH,Up to 5MP
|
|
|
Max Playback Channel
|
16CH
|
|
|
Onvif Protocols
|
Support
|
|
|
HDD
|
1 SATA interface
|
|
|
HDD Capacity
|
Up to 10TB capacity
|
|
|
Network interface
|
RJ45x1(10/100M)
|
|
|
BNC Output
|
–
|
|
|
Alarm Input/Output
|
–
|
|
|
RS485
|
–
|
|
|
USB
|
USB2.0x2
|
|
|
Operating Power
|
DC12V
|
|
|
Working Temperature
|
14 °F – 131 °F /-10 °C – 55 °C
|
|
|
Dimensions(W x H x D)
|
10.2″ × 8.7″ × 1.8” / 260 × 222 × 45mm
|
|
|
Weight (without hard disk)
|
≤ 2.4lbs / 1.1KG(without HDD)
|
|
